1350 Degree Fire Assay Crucible

Basic Information
Place of Origin: Hunan,China
Brand Name: ZEN
Model Number: ZEN-801
Minimum Order Quantity: 100PCS
Price: TO BE DISCUSS
Packaging Details: Kraft paper box,white box,egg tray
Delivery Time: 15-40 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000000 Piece/Pieces per Month
Detail Information
Material:: Fire Clay Shape: Round, Tapered Or According To Your Requirements
Dimensions:: Customized Packing: Custom Packing Acceptable
Port: Shenzhen,China Color: Milky White
Sample Days:: 5-10 Days Featrue:: High Casting Density;
Used: Used For Gold Ore Smelting, Melting,Assaying, Thermal Analysis Purpose :: Smelting, Melting,Assaying, Thermal Analysis
Application :: Used In Fire Assaying,Gold Assaying Thransport:: Air Transport: 5-9 Days
Application:: Fire Assaying, Gold Assaying, Precious Metal Analysis, Mineral Assaying, Laboratory Testing.
High Light:

80mm Fire Assay Crucible

,

1350 degree Fire Assay Crucible

,

1350 degree ceramic crucible for melting gold


Product Description

                 Fireclay Fire Assay Crucibles Mineral Assaying

    Fire assay it is a classical analytical method for applying metallurgical principles and techniques to analytical chemistry. To test the content of precious metals in minerals and metal products determined by melting and roasting.

Features:

1. Working Temperature 1350 degree(Fire assay working temperature less than 1150 degree);

2. Supply Ability with1200000 Pieces per Month;

3. Long Lasting, can be used 3-5 times.

4. Can withstand extremely corrosive fire assay environments;

5. High mechanical strength designed to withstand sever thermanl shocks.



Applications

Precious Metal Analysis

Mining Laboratory

Laboratory Testing

Mineral Assaying

Fire Assaying

Gold Assaying

Crucible used for lab



Chemical Composition

SiO2 54.6%
Al2O3 40.31%
Fe2O3 1.11%
TiO2 0.47%
CaO 1.28%
MgO 0.34%
K2O 0.61%
Na2O 0.39%
L.O.l(loss on ignition) 0.21%



Size detail:

Top diameter 105mm;Bottom diameter 55mm;High 145mm.




Product Specification

OD(mm) ID(mm) Outside height(mm) Inside height(mm) Bottom OD(mm) Capacity
80 70 80 66 55 165ml
90 78 105 85 55 245ml
93 80 115 95 55 295ml
95 80 125 105 55 345ml
93 82 135 110 55 380ml
93 82 135 115 55 370ml
90 80 155 136 55 380ml
95 83 140 118 48 390ml
80 62 130 110 42 310ml
90 82 132 120 55 330ml
88 80 132 118 50 325ml
108 90 140 125 55 630ml
110 95 155 135 55 710ml
105 95 155 132 55 680ml
105 95 145 109 55 650ml
90 84 165 150 55 430ml
120 110 160 140 75 750ml



Notes: We can supply the products according to customer's drawings, samples and performance requirement.



Packaging and Delivery:

1.Wooden Case

2.Carton Packing

3.Pallet

4.As Per Customer's Requirement

5.Shenzhen/Guangzhou/Shanghai Port



Prodution Process Flow

1350 Degree Fire Assay Crucible 1

1350 Degree Fire Assay Crucible 21350 Degree Fire Assay Crucible 3
